150mm Extractor Fan Standard
_This model is designed for simple switching on / off from a separate switch, e.g. light switch or spur unit (not supplied). It does NOT have a run-on timer. Normally used in a kitchen / utility or large bathroom (outwith zone 2) location.
_Mains 230/240V AC 50HZ. Power consumption: 25 watts.
_Extraction rate 68 litres per second, 245 cubic metres per hour
_Airvent is part of the Vent Axia group. IP22 rated. CE approved
_Dimensions: 225mm wide x 218mm tall x 46mm deep (beyond installed surface). 145mm diameter spigot, extends for 110mm. For connection to 150mm / 6 inch ducting
Square White Fan Grille to fit onto 150mm 6" Ducting. The Grille has a circular spigot on the rear to fix onto your solid or flexible ducting. There are screw holes in each corner and fixed slats at a slight gradient. The front of the grille measures approx 19cm square. The round spigot at the back has a diameter of slightly under 150mm and a depth of approx 2cm. The cover has an overall depth of approx 3cm and has curved edges to give a neat finish.
_Premium Plastic Grille with Rounded Edges - 19cm Square
_Round Spigot At Rear - 147cm diameter to fit onto 150mm ducting
_Curved Edges to Give a Neat Finish
_Screw Holes in Each Corner
_Fixed Slats at a Slight Gradient
Airvent 459309A 100MM 4'' Bathroom Extractor Fan With Timer And Automatic Shutters
_Automatic slow opening / closing backdraught shutter built in
_24 litres per second, 88 cubic metres per hour extraction rate
_20W power consumption
_Sound output 32dB(A) @ 3m
_Dimensions: 156mm wide x 156mm high x 42mm deep. 99mm diameter spigot, extends for 53mm
This fan has Integral Backdraught Shutters at the back of the Rear Spigot Slimline Front Grill is only 15mm Thick and approx 6 inches square Sleek Modern Design with Rounded Corners Suitable for Wall Mounting (not suitable for window or ceiling mounting) 220 - 240V AC 50Hz IP44 Extract Performance - 88 m3/hr 24L/sec Fan Speed - 2500rpm Noise Level 32dBA Suitable for 4" (100mm) ducting This fan does not have a integrated pullcord and would normally be wired to a separate switch eg; pullcord or light switch Please note : Current stock has the Airvent logo on the bottom right corner as shown in last photo
_4" Bathroom Extractor Fan
_Integral Backdraught Shutters
_Sleek Modern Design with Rounded Corners
_Slimline Front Grille - 15mm Thick
_Suitable for Wall Mounting
PLEASE NOTE THIS IS THE LARGER MODEL FAN FOR CONNECTION TO 150MM / 6" DIAMETER DUCTING This model incorporates a condensation (humidity) sensor which automatically switches the fan on when the condensation level builds up. Once the condensation clears the fan turns off. It can also be connected to work with the room light switch. Requires at least a permanent unswitched live and neutral connection. If the timer functionality is required then an additional switched live connection is required.
_Mains voltage 220/240V AC 50Hz. See product description for electrical connection requirements
_Extraction rate 63 litres per second, 230 cubic metres per hour
_Power consumption: 25 watts. Sound output 40dB(A) @ 3m
_Spring operated backdraught shutter. Class II - double insulated. IP44 rated
_Dimensions: 205mm wide x 205mm tall x 50mm deep (beyond installed surface). 150mm diameter spigot, extends for 60mm. For connection to 150mm / 6 inch ducting
Airvent 435404 Axial Low Profile Extractor Fan 150mm / 6'' - Timer Model
_Front Cover Measures Approx 8" Square
_150mm size refers to Size of the Fan inside the Housing
AirVent Axial Kitchen Fan 150mm with Pull Cord and Shutters 435103
_Model number 5031680870060.
_Adapt normal for the cuisines or the grandes salles de bains.
_Griglia anteriore section misura approx. 21cm x 21cm.
This model incorporates a run-on timer which operates in connection with the room light switch. When the light is switched on the fan starts, when the light is switched off the fan continues to run for the pre-set period. Permanent live, switched live and neutral wires (3 cores + earth) are required at the fan position in order to function correctly. This model is normally suitable for kitchen, utility room and larger bathrooms (outwith zone 2)
_Voltage 230/240V AC 50Hz. Extraction rate 61 litres per second, 220 cubic metres per hour
_Power consumption: 25 watts. Sound output: 45dB(A) @ 3m
_Timer over-run adjustable 1 - 25 minutes. Class II double insulated
_IP22 rated. CE approved. Airvent is part of the Vent Axia group
_Dimensions: 226mm wide x 218mm tall x 48mm deep (beyond installed surface). 145mm diameter spigot, extends for 80mm. For connection to 150mm / 6 inch ducting
Model: 434446A ¯100mm, axial, inline, shower fan kit with electronic overrun timer adjustable from 5 to 30 minutes. The factory setting is 15 minutes. Kit Includes Fan, two grilles, fixings and 3m flexible PVC ducting Quiet operation Timer model (5-30 minutes) Technical Specification IP44 rated. CE marked in accordance with all the relevant EEC Harmonised Directives. Double insulated, class II motor fitted with Thermal Protection. Airflow Installed: 82m3/hr installed Airflow, fan only, free air: 108m3/hr Technical Data: Rated Voltage 220-240v-50Hz Rated Wattage 14W Noise Level 37dB(A) Grille Dimensions Height: 170mm Width: 170mm Length: 60mm Dimensions Height-100mm Width-100mm Depth-137mm
_Full Kit comprising of Inline Fan, 2 Grilles, 3 metres of Flexiduct and Fixings
_Airvent Brand (made at Vent Axia)
_Timer Model - Can be wired so Fan stays on when light switched off
_Requires: Premanent Live, Switched Live, Neutral
_Double Insulated: No Earth Required
For exhaust ventilation of residential premises.Wall surface or ceiling mounting. turn-off delay time regulated between 2 and 3 min.
_Blauberg slim axial extract fan with over run timer
Blauberg Ventilation Grille Chrome effect.
_Ventilation grille which can be used as air intake or extract for ventilation systems
_High quality polished chrome effect finish
_For connection to 100mm diameter ducting. 2 part item, cover is removable for cleaning / painting etc
_CE Approved
_Dimensions: 141mm diameter x 10mm deep (visible). 99mm diameter spigot, extends for 50mm
A Powerful 300mm 12" Commercial/Industrial Extractor Fan with Automatic Shutters. Shutters are thermally activated so they open slowly once the fan has been on for several minutes - the shutters will close slowly several minutes after turning the fan off.FULL SPECIFICATION CAN BE VIEWED ON THE MANUFACTURERS WEBSITE: http://www.anda.co.uk/products/ventilation/300mm-commercial-fan-automatic-shutters
_Large 300m Extractor Fan for Shops, Kitchens, Restaurants, Pubs, Factories etc
_A 2 Speed/Reversible Controller is available to buy separately
_Manufactured impact resistant high gloss ABS for strength and durability
_Dimensions: Height - 403mm Width - 403mm Depth - 180mm
_Motor fitted with thermal over load protection
Fan has thermally activated shutters which automatically open/close slowly once the fan has been switched on/off. For wall, ceiling or window mounting (wall and window kits available to buy separate). Axial fans are designed to move air over short distances i.e up to 2meters in length. Front grille measures approx 6" x 6" round spigot to rear approx diameter 4"
Airvent 459294A 4'' 100mm White Bathroom Fan with Humidistat - Made at Vent Axia
_Mains voltage 230/240V AC 50Hz
_Extraction rate 21 litres per second, 75 cubic metres per hour
_Power consumption: 16watts, Sound output: only 30dB(A) @ 3m
_Pullcord override
_IP44 rated, CE approved
Bathroom / Toilet Extractor Fan with over-run timer
_Mains 230/240V AC. Extractor fan suitable for small bathroom situation.
_Timer over-run continues to run fan after room light is switched off (permanent live required)
_22 litres per second / 80 cubic metres per hour extract rate. 15 watts power consumption.
_Sound output 48dB(A) @ 3m. IP22
_156mm wide x 156mm high x 48mm deep. 99mm spigot that extends for 53mm
Airvent White Kitchen Extractor Fan with Pullcord 6'' 150mm - Wall or Window
_Mains voltage 230/240V AC 50Hz
_Extraction rate 68 litres per second, 245 cubic metres per hour
_Power consumption: 25 watts, Sound output: only 45dB(A) @ 3m
_Pullcord switch
_IP22 rated, CE approved
This model incorporates a condensation (humidity) sensor which automatically switches the fan on when the condensation level builds up. Once the condensation clears the fan turns off. Airvent are part of the Vent Axia group Dimensions: 224mm wide x 224mm tall x 15mm deep (beyond installed surface). 145mm diameter spigot, extends for 110mm. For connection to 150mm / 6 inch ducting
_Mains voltage 230/240V AC 50Hz
_Extraction rate 63 litres per second, 228 cubic metres per hour
_Power consumption: 25watts, Sound output: only 45dB(A) @ 3m
_Double spring operated backdraught shutter
_IP44 rated, CE approved
Airvent 435403 - Kitchen Extractor Fan 6''/150mm - Low Profile/Slimline - With Integral Butterfly Style Shutters
_Mains 230/240V AC 50Hz. Power consumption: 25 watts
_Extraction rate 63 litres per second, 228 cubic metres per hour
_Sound output: 40dB(A) @ 3m. Double spring operated backdraught shutter
_IP44 rated. CE approved
_Dimensions: 224mm wide x 224mm tall x 15mm deep (beyond installed surface). 145mm diameter spigot, extends for 110mm. For connection to 150mm / 6 inch ducting
Low voltage (SELV) 12V extractor fan with separate transformer. This fan is suitable for use within zone 1, shower enclosures etc, providing the transformer unit is located outwith zone 2, e.g. in an adjacent cupboard or loftspace. This model incorporates a run-on timer which operates in connection with the room light switch. When the light is switched on the fan starts, when the light is switched off the fan continues to run for the pre-set period. Permanent live, switched live and neutral wires (3 cores + earth) are required at the transformer position in order to function correctly. Suitable for ceiling mounting as long as the ducting is kept shorter than 1.5m. Fan dimensions: 160mm wide x 160mm tall x 10mm deep (beyond installed surface). 99mm diameter spigot, extends for 80mm. For connection to 100mm / 4 ducting. Transformer dimensions: 149mm wide x 88mm tall x 67mm deep
_21 litres per second, 75 cubic metres per hour extraction rate
_For use with fluorescent lamp wattages 4-8, 13, 15, 18-20, 25-65 & 80 Watt
_Manufactured to BS EN 60155
