Low voltage (SELV) 12V extractor fan with separate transformer. This fan is suitable for use within zone 1, shower enclosures etc, providing the transformer unit is located outwith zone 2, e.g. in an adjacent cupboard or loftspace. This model incorporates a run-on timer which operates in connection with the room light switch. When the light is switched on the fan starts, when the light is switched off the fan continues to run for the pre-set period. Permanent live, switched live and neutral wires (3 cores + earth) are required at the transformer position in order to function correctly. Suitable for ceiling mounting as long as the ducting is kept shorter than 1.5m. Fan dimensions: 160mm wide x 160mm tall x 10mm deep (beyond installed surface). 99mm diameter spigot, extends for 80mm. For connection to 100mm / 4 ducting. Transformer dimensions: 149mm wide x 88mm tall x 67mm deep
_21 litres per second, 75 cubic metres per hour extraction rate
_For use with fluorescent lamp wattages 4-8, 13, 15, 18-20, 25-65 & 80 Watt
_Manufactured to BS EN 60155
AIRVENT Kitchen/Utility Room Axial Extract Fan with over run timer and internal shutters, suitable for panel, wall or window mounting when using the appropriate accessory, such as tube or flexi ducting and an external grille. This listing is for the fan only. Requires two live wires!
_AIRVENT Kitchen/Utility Room Axial Extract Fan with over run timer and internal shutters, suitable for panel, wall or window mounting
_Requires 2 Live Wires: A Switched Live and a Permanent Live as well as a Neutral
_No Earth Required as Double Insulated
Airvent 401901 Wall Fixing Kit in White for 4'' Extractor Fan
_Kit consists of an External Fixed Grille and a Length of 4" Solid Tube
_Grille is White with Fixed Louvres with a 4" Round Spigot to Rear
_Solid Tube is approx 4" in diameter and approx 35cm long
White Ducting that stretches out to approx 3m long. The ducting is approx 6" in diameter. Commonly used with extractor fans and larger tumble dryers/air conditioning units
