JG Underfloor Spreader Plates (From Above) is an underfloor heating (UFH) pipe fixing system designed for use with timber suspended or floating floors, where a low height build up is required. 15mm pipe is installed into single or double grooved aluminium spreader plates that transmit heat evenly across the floor. insulation is placed in the void below the plates to minimise downward heat loss. Ideal for new builds, extensions and renovations, especially first floor levels. For existing floor structures install between battens and for new floors, fix between existing joists. If the floor can be raised, floors can also be counter-battened to make installation even easier. Timber floor pipe fixing system Aluminium heat diffusion plates Options for traditional or composite joists Low height build up Medium heat output and response Ideal for all room sizes, single or multi room Suitable for underfloor heating applications only

Read more less

JG Underfloor Overfit Board is a low-profile underfloor heating (UFH) pipe fixing system designed for existing floor structures. Ideal for retrofit projects, the pipe fixing system provides low height build up and is suitable for ground and first floor level applications. 15mm pipe is easily installed into a grooved foil-faced panel over an existing subfloor. Maximum pipe circuit length is 100m with a recommended flow temperature of 50-60ºC. Existing floor pipe fixing system Lightweight insulated panel with compressive strength Grooved foil-faced panel with 200mm centres Low height build up Medium to low heat output and response (approx. 50-60w/m2) Ideal for rooms of all sizes and shapes Suitable for underfloor heating applications only

Read more less

JG Underfloor Underfit Board is a low-profile underfloor heating (UFH) pipe fixing system designed for existing timber suspended or floating floor structures. Ideal for retrofit projects, the pipe fixing system provides no height build up and is suitable for ground and first floor level applications. 15mm pipe is easily installed into a grooved foil-faced panel over an existing floor, either between battens or under the floor between joists. Maximum pipe circuit length is 100m with a recommended flow temperature of 50-60ºC. Existing floor pipe fixing system Lightweight insulated panel Grooved foil-faced panel with 200mm centres Low height build up Medium to low heat output and response (approx. 50-60w/m2) Ideal for rooms of all sizes and shapes Suitable for underfloor heating applications only

Read more less

Fixes and secures underfloor heating pipework using a mounting rail JG Underfloor mounting rail is designed for screed floor underfloor heating (UFH) applications when the insultation is too thin for staples. Suitable for new builds and extensions, especially ground floor levels, this pipe fixing method is fast and simple to install and offers high heat output and response. 15mm pipe can be easily secured to the clip rails on top of the rigid insulation sheets, which is then placed over the concrete subfloor. JG Underfloor Rail Pins should be used to fix the JG Underfloor mounting rail. Features and benefits Screed pipe fixing system 2-metre mounting rail Easily clips pipe onto the rail Ready-made pipe spacing Pre-scored at 100m intervals for easy cutting High heat output and response Ideal for large regular shaped rooms Suitable for underfloor heating applications an 15mm pipe only SPECIFICATION Brand JG Speedfit Manufacturer Guarantee 2 Year Manufacturer's Guarantee (T&Cs Apply) Model No JGUFHRAIL Pack Size 1 Pieces in Pack/Case 1 Product Length 2 m Product Type Clip Rail

Read more less

JG Underfloor Edge Strip is used around the edge of a solid (screed) floor to provide an expansion gap as the floor heats up and cools down. It also has insulating properties ensuring heat loss is kept to a minimum. Foam edge strip for screed floors Acts as an expansion gap when the floor heats up and cools down

Read more less

JG Underfloor Pipe Staples are used to quickly and securely fix underfloor heating pipework to insulation. Suitable for screed floor applications, this method of pipe fixing is cost-effective and offers high heat output and response. The pipe staples are barbed to ensure a secure grip and are easy to install when using a JG Underfloor Staple Gun. Screed pipe fixing system Barbed staples secure pipe to insulation Ideal for regular and irregular shaped rooms Conduit required when pipework runs through adjacent rooms Suitable for underfloor heating applications only

Read more less

For I beam joists to be used with composite joists and are fixed from below. Speedfit Pipe is fixed in the grooves of the plates, insulation is placed in the void below the plates to minimise downward heatloss. Technical Specification Brand JG Speedfit Manufacturer ID JGUFHSP165 Type Speedfit Size (mm) 165

Read more less

JG Underfloor Staple Gun is used for securing staples to the pipe and insulation in screed floor applications. Robust staple gun Easy repeatable action Use with JG Underfloor staples (not included) Suitable for underfloor heating applications only

Read more less

JG LowFit™ 20mm castellated panels are designed to provide a high output, low height, screeded underfloor system. The 20mm panel has equally spaced castellations at 50mm to allow 15mm pipe to be clipped in securely and accurately as per design specifications Installation of the panels is fast and simple as it features an overlapping alignment system for simple hassle-free panel laying, as well as a super strong adhesive backing. This allows for the panel to be installed directly onto the existing sub floor structure. The open grid design ensures the screed layer poured on top flows smoothly and evenly over the panel. Ideal solution for screed floor applications Easy to install low profile 20mm panel for 15mm pipe (total floor height including screed is 23-25mm) Excellent performance with a high heat output at low flow temperatures Versatile application that is compatible with 50, 100, 150 or 200mm pipe spacing (centres) Open grid design allows better flow of screed around pipes and castellations for a solid stable floor makeup Each panel has a peel off adhesive backing film for hassle-free and secure installation to the subfloor Panels are linked together with a simple click together system ensures accurate alignment Made from 100% recyclable material Suitable for underfloor heating applications only

Read more less

JG LowFit™ mesh panels are designed to be installed over existing timber or concrete floors, while maintaining a low overall floor height. The 16mm panel is lightweight with high compressive strength. The mesh layer allows for tiling directly to the panel* and is pre-grooved to include return bends that eliminate the need for additional panel variations. *In some cases, a decoupling layer may be required, always consult the flooring supplier for advice. Ideal solution for laying over timber or concrete floors Easy to install 16mm panel allows for 12mm pipe applications and a lower overall floor height High heat output from a low-level floor build Light-weight system with high compressive strength Return bends are indented into the board making installation easy. Mesh layer allows for tiling directly onto the surface, ensuring a lower overall floor height. Made from 100% recyclable material Suitable for underfloor heating applications only

Read more less

JG Underfloor control unit is used to provide heating to a conservatory or room extension up to 30m². It is suitable for use when the boiler serving the existing heating system has the capacity to take the extra output from 2KW to 3KW and the maximum area to be heated is 30m2 or less. The unit is pre-assembled and pre-wired to allow for a fast and simple installation. It can be plugged into any convenient electrical socket or spur. It also has integral ball valves for isolation from the primary heating system, an adjustable blending valve and a six-metre head circulation pump. It should ideally be connected to the main central heating flow and returns distribution system, but it can connect to the nearest radiator supply pipe. In this case, the pump will not operate independently and will only obtain hot water when the radiator system is on. Pre-wired and pre-assembled for a fast a simple installation Single zone control unit for conservatories and extensions JG Speedfit push-fit connections Plug directly into an electrical socket or spur Integral ball valves for isolation from the primary heating system Adjustable blending valve and 6m head circulation pump Anti-vibration mounting bracket Suitable for underfloor heating applications up to 30m2

Read more less

Manufactured to the highest standards, JG LowFit™ underfloor heating manifolds are made from stainless steel and are available in a range of sizes from 2 to 12 ports. Fast and simple to install, JG LowFit™ manifolds uniquely feature JG Speedfit push-fit connections and come with a pre-mounted bracket and vibration isolation mount. Manifolds can also be assembled to suit left or right-hand supply. Each manifold is supplied fully assembled with flow and return rails, adjustable flow meters, an automatic air vent and fill valve. Protective dust caps are supplied on the return rail, which can be removed when installing circuit actuator valves to open and close the flow of water to each pipe loop. High performance stainless steel manifold Fast and simple installation using 12mm Speedfit connections eliminating the need for further reducing adaptors. Easy to fit due to pre-mounted brackets and vibration isolation mount Integral Automatic Air Vent discharges air that could impact circulation Valves on the return manifold are compatible with thermoelectric heads Rail valves on the return rail allow circuit actuators to be easily connected Versatile assembly for left or right-hand supply Suitable for use with JG Speedfit PEX and polybutylene barrier pipe (inserts required)
