Replaceable jaw plates are available for all Mechanics, Fitters, multi-purpose and Engineers vices. They are hardened, CNC machined and supplied in pairs complete with screws or bolts ready to fit.Replaceable jaw plates for No.5 vice. Jaw Width. 125mm (5 in).
The MaxSteel light-duty bench vice is made with durable cast iron construction for strength. The roll-formed screw threads ensure smooth operation and durability and the chrome plated hardware resists corrosion. The base bolts directly to the workbench surface for stability and also swivels and locks for versatility. Jaw width: 115mm (4in).
Record Irwin V175B Woodcraft Vice is designed for the user who requires a more robust vice which is permanently fixed. The main screw has a rolled 2-start acme thread which ensures a smooth strong action with the integral nut in the vice body. A top quality vice at an economical price.Boxed. Jaw Width: 175mm (7in).Jaw opening: 165mm (6.1/2in).
Record quick-release woodworking vices are fitted with quick release mechanisms, simple squeeze the trigger and a quick-release vice will be opened and closed without using the mainscrew. Large and small work pieces can be quickly interchanged, while releasing the trigger returns the mechanism to normal for fine adjustment. An ideal addition to the engineering workshop or tool room. For clamping and holding wood work pieces. The adjustable front stop or dog gives an additional cramping facility when used in conjunction with a bench stop. A useful addition which provides a normal vice and tail vice in one tool. Two steel guide rods to reduce wear and ensure a smooth parallel action Jaws 'toe in' so that when pressure is applied they give an even clamping over the whole depth of the work piece. Adjustable dog used in conjunction with bench stops fitted into the bench top. Location holes are provided so you can fit your own choice of wooden cheeks to protect the work pieceJaw Width. 270mm (10 1/2in). Jaw opening: 380mm (15in)
Record quick-release woodworking vices are fitted with quick release mechanisms, simple squeeze the trigger and a quick-release vice will be opened and closed without using the mainscrew. Large and small work pieces can be quickly interchanged, while releasing the trigger returns the mechanism to normal for fine adjustment. An ideal addition to the engineering workshop or tool room. For clamping and holding wood work pieces. The adjustable front stop or dog gives an additional cramping facility when used in conjunction with a bench stop. A useful addition which provides a normal vice and tail vice in one tool. Two steel guide rods to reduce wear and ensure a smooth parallel action Jaws 'toe in' so that when pressure is applied they give an even clamping over the whole depth of the work piece. Adjustable dog used in conjunction with bench stops fitted into the bench top. Location holes are provided so you can fit your own choice of wooden cheeks to protect the work pieceJaw Width. 230mm (9in).Jaw opening: 330mm (13in)
The Faithfull Light-Duty Mechanics Vice for light to medium-duty applications is made from Spheroidal graphite (SG) cast iron, also known as SG iron, or Ductile Iron. During the manufacturing process the Graphite (carbon) element of the steel is shaped and aligned and adds the important “spherical” aspect to the name. This makes these vices both virtually unbreakable as well as much lighter than conventional grey cast iron, the material traditionally used for the construction of mechanics vices. Manufactured and machined to close tolerances and is designed to offer smooth operation and reliability. An integral anvil assists with the hammering of materials. Supplied with a swivel base allowing the vice to be manoeuvred through 360 degrees, and locked in position as required. This base can be bolted onto a work surface for additional stability. Plastic magnetic jaws can be ordered separately to allow the vice to be used for the clamping of soft, polished and round materials, without causing any damage. Code: FAIMAGVJ100. Specifications: Jaw Width: 100mm (4in).Jaw Opening Capacity: 115mm (4.1/2in).Clamping Force: up to 1000 N (kg F) / 1.0 Kilo Newton.Weight: 4.43kg.
Record IRWIN Mechanics vices are the most popular and widely used general purpose vice for light to medium-duty applications. The vice has high quality grey iron castings that resist distortion under severe pressure, with a smooth action provided by dovetailed, long barrelled, unbreakable nut and hardened steel replaceable jaw plates.Record Irwin No.6 Mechanics Vice. Jaw Width: 150mm (6in).
This Faithfull Woodworking Vice is manufactured from close grain grey cast iron with a steel mainscrew for a long and trouble-free working life. Accurately machined housing coupled with solid steel guide rods assure a smooth sliding true parallel action for the jaw, free from side or cross deflection. This vice has a toe-in feature so that when fully closed the jaws only meet at the top to provide even clamping on the whole depth of the workpiece. The adjustable front stop or dog gives an additional clamping facility when used in conjunction with a bench stop. FAIVW175DQ: Opening: 200mm (8in).FAIVW230DQ: Opening: 330mm (13in).This Faithfull Woodwork Vice Quick-Release with Dog has the following specification: Jaw Width: 230mm (9in).Opening: 330mm (13in).
Designed for drill press work, the sliding jaw is a non lifting swivel type capable of holding any shape of workpiece.The horizontal and vertical vees accomodate round sections securely and the base is slotted to enable the vice to be bolted to drill press tables. Base, end face and side faces are machined to assist quick and accurate positioning.Features include, unique swivel jaw for any shape of workpiece.Cross drilled handle with tommy bar for extra leverage. Precision machined base and end face for horizontal and vertical mounting. Jaw Width. 100mm (4in).Jaw Opening: 75mm (3in).
The MaxSteel heavy-duty bench vice is made from cast iron for strength and durability. The base bolts directly to the workbench surface for stability, and swivels and locks for versatility. Roll-formed screw threads ensure smooth operation and durability. Chrome plated hardware resists corrosion.Size: 100mm (4 in).
The Stanley multi-angle hobby vice features a patented ball joint which allows you to rotate your project a full 360° and lock it at any angle. Multiple positions for convenience and easier access. 3in jaw opening holds a wide range of items. Removable rubber jaw covers a wide range of applications for protecting delicate finishes. The large C-clamp mount attaches to work surfaces up to 2.3/8in thick - also suitable for heavy-duty applications. Jaw capacity: 75mm (3in).
Record IRWIN Mechanics vices are the most popular and widely used general purpose vice for light to medium-duty applications. The vice has high quality grey iron castings that resist distortion under severe pressure, with a smooth action provided by dovetailed, long barrelled, unbreakable nut and hardened steel replaceable jaw plates.Record Irwin No.8 Mechanics Vice. Jaw Width: 200mm (8in).
Record IRWIN Mechanics vices are the most popular and widely used general purpose vice for light to medium-duty applications. The vice has high quality grey iron castings that resist distortion under severe pressure, with a smooth action provided by dovetailed, long barrelled, unbreakable nut and hardened steel replaceable jaw plates.Record Irwin No.4 Mechanics Vice.- Jaw Width: 115mm (4.1/2in).
The Woodcraft vice has 150mm (6 in) jaws and it is designed to be mounted underneath the bench so that the top of the jaws are flush with the bench top. Toe-in at the top of jaws ensures firm grip and jaws have provision for attachments of wooden cheeks to protect the workpiece. Accurately aligned steel slides and rolled 2-start acme thread for smooth action. Jaw Opening: 115mm (4 1/2in).
The IRWIN Record No.23 Fitters vice is a medium-duty vice for industrial fitting and training workshops where work ranges from small fitting and filing work to the assembly and fitting of larger components. The lever adjustment allows instant movement of the jaws through a half-nut mechanism working in conjunction with the threaded screw. (quick release). Supplied with hardened steel replaceable jaw plates. Jaw Width. 115mm (4 1/2 in).
The Faithfull Hobby vice is manufactured from high quality grey iron castings and machined to close tolerances to ensure a smooth operating sliding jaw. Ideal for use by DIY enthusiasts or model makers and finished with an attractive enamelled coating. The mainscrew and handle are chromed to provide better corrosion resistance. Fitted with an integral clamp for portability Jaw width: 60mm (2.1/2in).Opening: 50mm (2in).
The MaxSteel heavy-duty bench vice is made from cast iron for strength and durability. The base bolts directly to the workbench surface for stability, and swivels and locks for versatility. Roll-formed screw threads ensure smooth operation and durability. Chrome plated hardware resists corrosion.Size: 150mm (6 in).
The Record IRWIN REC25 No.25 Fitters Vice 150mm (6 inch) is a medium-duty vice for industrial fitting and training workshops where work ranges from small fitting and filing work to the assembly and fitting of larger components.The lever adjustment allows instant movement of the jaws through a half-nut mechanism working in conjunction with the threaded screw. (quick release). The vice also has hardened steel replaceable jaw plates. Jaw Width: 150mm (6 inch)
Woodworking vice for the professional user who requires a plain screw action.The plain screw works through a separate unbreakable nut securely housed beneath the body seating to ensure constant alignment of screw mechanism. Fitted with front dog.Jaw Width. 175mm (7in). Jaw opening: 200mm (8in)
The IRWIN Record Workshop Vice, with anvil and swivel base, is specifically designed for medium-duty workshop applications for both, the professional craftsman and the DIY enthusiast. Strong and durable, the body and sliding jaw are cast from close grained grey iron which is machined on all friction surfaces for a smooth reliable action. The jaws, handle and main screw are steel. The main screw has a two-start rolled acme thread to speed the jaws from fully closed to fully open with a minimum of winding.The IRWIN Record T3TON3VS Workshop Vice, with Anvil and Swivel Base 4in, is specifically designed for medium-duty workshop applications for both the professional craftsman and the DIY enthusiast.Strong and durable, the body and sliding jaw, width 100mm, are cast from close grained grey iron which is machined on all friction surfaces for a smooth reliable action.The jaws, handle and main screw are steel. The main screw has a two-start rolled acme thread to speed the jaws from fully closed to fully open with a minimum of winding. Specification: Jaw Width: 100mm (4in).
Record IRWIN Mechanics vices are the most popular and widely used general purpose vice for light to medium-duty applications. The vice has high quality grey iron castings that resist distortion under severe pressure, with a smooth action provided by dovetailed, long barrelled, unbreakable nut and hardened steel replaceable jaw plates.Record Irwin No.3 Mechanic Vice. Jaw Width: 100mm (4in)
Record IRWIN Mechanics vices are the most popular and widely used general purpose vice for light to medium-duty applications. The vice has high quality grey iron castings that resist distortion under severe pressure, with a smooth action provided by dovetailed, long barrelled, unbreakable nut and hardened steel replaceable jaw plates.Record Irwin No.5 Mechanics Vice Jaw Width: 125mm (5in).
The Faithfull sturdy vice has been constructed from graded cast iron and designed for use with bench drills and drill presses. Its compact low profile design makes it suitable for a multitude of metal and woodworking applications. The vice features a precision ground base and vice bed for smooth lateral movement of the locking jaw. The fixed jaw has three longitudinal and one transversal prism to facilitate clamping of flat work pieces. The locking spindle moves inside the hollow handle grip allowing the vice to be tightened at any position on the drilling table. Elongated clamping slots also permit rapid adjustment of the vice on the work table. Jaw width 75mm (3in) Jaw opening (2.3/4in) 5 year Guarantee.
Woodworking vice for the professional user who requires a plain screw action.The plain screw works through a separate unbreakable nut securely housed beneath the body seating to ensure constant alignment of screw mechanism. Fitted with front dog.Jaw Width: 230mm (9in). Jaw opening: 330mm (13in)
