The DEWALT Extreme 2 Metal Drill Bit is suitable for portable or stationary drilling of steel, alloyed and non alloyed, up to 900N/mm. Particularly suited to drilling sheet or thin materials where accurate burr-free holes are required. Very effective in wood and plastic materials. The patented split pilot point design eliminates walking/slipping on contact.This DEWALT Extreme 2 Metal Drill Bit has the following specification: Tip Diameter: ;6.0mm.Working Length: ;57mm.Overall Length: ;93mm.Pack Quantity: 10.
The DEWALT Extreme 2 Metal Drill Bit is suitable for portable or stationary drilling of steel, alloyed and non alloyed, up to 900N/mm. Particularly suited to drilling sheet or thin materials where accurate burr-free holes are required. Very effective in wood and plastic materials. The patented split pilot point design eliminates walking/slipping on contact.The DEWALT DEWDT5545QZ drill bits have the following specifications: Tip Diameter: 9.5mm.Working Length: 78mm.Overall Length: 125mm.Pack Quantity: 10.
The DEWALT Extreme 2 Metal Drill Bit is suitable for portable or stationary drilling of steel, alloyed and non alloyed, up to 900N/mm. Particularly suited to drilling sheet or thin materials where accurate burr-free holes are required. Very effective in wood and plastic materials. The patented split pilot point design eliminates walking/slipping on contact.This DEWALT Extreme 2 Metal Drill Bit has the following specification: Tip Diameter: 3.5mm.Working Length: 39mm.Overall Length: 70mm.Pack Quantity: 10.
The DEWALT Extreme 2 Metal Drill Bit is suitable for portable or stationary drilling of steel, alloyed and non alloyed, up to 900N/mm. Particularly suited to drilling sheet or thin materials where accurate burr-free holes are required. Very effective in wood and plastic materials. The patented split pilot point design eliminates walking/slipping on contact.This DEWALT Extreme 2 Metal Drill Bit has the following specification: Tip Diameter: 1.5mm.Working Length: 18mm.Overall Length: 40mm.Pack Quantity: 10.
The DEWALT Extreme 2 Metal Drill Bit is suitable for portable or stationary drilling of steel, alloyed and non alloyed, up to 900N/mm. Particularly suited to drilling sheet or thin materials where accurate burr-free holes are required. Very effective in wood and plastic materials. The patented split pilot point design eliminates walking/slipping on contact.This DEWALT Extreme 2 Metal Drill Bit has the following specification: Tip Diameter: 2.0mm.Working Length: 24mm.Overall Length: 49mm.Pack Quantity: 10.
The DEWALT HSS G Jobber Drill Bit is a precision ground twist drill bit for rapid drilling, long life and excellent concentricity. It has been manufactured from High Speed Steel that conforms to DIN 338. The drill bit is ground from solid stock and has a right hand cutting, type N flute with a precision ground end at 118° point angle.This DEWALT HSS-G Jobber Drill Bit has the following specification: Diameter: 3.5mm.Length: 70mm.Working Length: 39mm.Pack Quantity: 2.
The DEWALT HSS G Jobber Drill Bit is a precision ground twist drill bit for rapid drilling, long life and excellent concentricity. It has been manufactured from High Speed Steel that conforms to DIN 338. The drill bit is ground from solid stock and has a right hand cutting, type N flute with a precision ground end at 118° point angle.This DEWALT HSS-G Jobber Drill Bit has the following specification: Diameter: 11.0mm.Length: 142mm.Working Length: 94mm.Pack Quantity: 1.
A777 Metric Cobalt Jobber Drill Bits have a heavy-duty, 135° split point for use when greater heat is generated during drilling, e.g on higher tensile tougher materials and in particular the Aerospace Industry. Specification Flute Geometry: Standard Helix, Right hand spiral, Thick WebPoint Angle: 0.30 mm - 0.95 mm 118° Conical point1.00 mm to 1.40 mm inclusive 135° 4 facet point1.50 mm and above 135° split point sizes (Split point geometry to NAS 907 Areospace Specification type P3 Point) Surface Treatment: BronzeMaterial: HSCo Cobalt steel DIN 338 RN / BS328 / ISO 235Tip diameter: 5.50mmWorking length: 57mm.Overall length: 93mm.
Dormer A170 Parallel shank drills with a standard helix, right hand spiral, 1/2in parallel shank drill, often referred to as a Blacksmiths drill. General purpose drill, ideal for a wide range of materials where chuck holding capacity is limited.Suitable for both hand and machine use. Tip diameter: 18.0 mm HSS.Working length: 84mm.Overall length: 157mm.
Dormer A100 Metric HSS jobber drills are suitable for use in the majority of general purpose engineering applications. They have good self-centring capability on a wide range of materials and are suitable for both hand and machine use. DIN338RNBS328ISO235Tip diameter: 2.40mm.Working length: 30mm.Overall length: 57mm.
Dormer A100 Metric HSS jobber drills are suitable for use in the majority of general purpose engineering applications. They have good self-centring capability on a wide range of materials and are suitable for both hand and machine use. DIN338RNBS328ISO235Tip diameter: 18.00mm.Working length: 130mm.Overall length: 191mm.
Dormer A100 series general purpose HSS jobber drills are suitable for use in the majority of general purpose engineering applications. They have good self-centring capability on a wide range of materials and are suitable for both hand and machine use. DIN338RNBS328ISO235Tip diameter: 1/16in.Working length: 20mm.Overall length: 43mm.
The Dormer Imperial A002 TiN Jobber Drill Bits have a TiN tip coating for increased tool life and performance. It has a self-centring split point for superb hole quality and positional accuracy. It will drill steel, stainless, cast iron, ceramics, plastics and many other materials with ease. Suitable for both hand and machine use. Made to DIN 338RN/BS328/ISO 235 standards.Tip diameter: 9/32in. Working length: 69mm.Overall length: 109mm.
Dormer A100 Metric HSS jobber drills are suitable for use in the majority of general purpose engineering applications. They have good self-centring capability on a wide range of materials and are suitable for both hand and machine use. DIN338RNBS328ISO235DIN338RNBS328ISO 235Size.1.30mm
Dormer A100 Metric HSS jobber drills are suitable for use in the majority of general purpose engineering applications. They have good self-centring capability on a wide range of materials and are suitable for both hand and machine use. DIN338RNBS328ISO235Tip diameter: 2.20mm.Working length: 27mm.Overall length: 53mm.
Dormer Metric A002 TiN Jobber Drill Bits have a TiN tip coating for increased tool life and performance. It has a self-centring split point for superb hole quality and positional accuracy. It will drill steel, stainless, cast iron, ceramics, plastics and many other materials with ease. Made to DIN 338RN/BS328/ISO 235 standards. PLEASE NOTE ALL sizes under 2.0mm are NOT TiN Coated.Tip diameter: 6.80mm.Working length: 69mm.Overall length: 109mm.
The Irwin Metric TCT (Tungsten Carbide Tipped) Drill Bits offer precision drilling with stationary machines in hardened steel, cast iron, bronze alloys and manganese alloyed steel. The C2 Carbide Tip will drill hardened material up to a hardness of 50 Rockwell C and is four facetted ground for low drilling pressure and perfect centring. The body of the drill bit is made from Chrome Vanadium Steel, hardened to 56 Rockwell C. A coolant should always be used when drilling with TCT twist drill bits. Irwin suggest the use of a 3- 6% emulsion. The coolant will extend the lifetime of the drill bit.Irwin HSS TCT tip drill bit. Specifications:Diameter: 2.5mm.Total length: 57mm.Working Length: 30mm.
The Irwin HSS Pro Drill Bit manufactured from high quality HSS steel. They have precision ground cutting edges for fast drilling and perfect finishing, a ground flute for maximum accuracy and fast chip removal and a universal 118º point shape for drilling a wide selection of materials.The Irwin IRW10502266 HSS Pro Drillbits comes in a bulk pack of 10 with the following dimensions:Drillbit diameter: 3.5mmTotal length: 70mmWorking Length: 39mm
Dormer Metric A002 TiN Jobber Drill Bits have a TiN tip coating for increased tool life and performance. It has a self-centring split point for superb hole quality and positional accuracy. It will drill steel, stainless, cast iron, ceramics, plastics and many other materials with ease. Made to DIN 338RN/BS328/ISO 235 standards. PLEASE NOTE ALL sizes under 2.0mm are NOT TiN Coated.Tip diameter: 4.20mm.Working length: 43mm.Overall length: 75mm.
The G & J Hall CONECUT® is a versatile hole-cutting tool for rapid drilling and enlarging holes in thin materials up to 2mm thick. Designed for industrial applications, the diameter of the hole increases as the CONECUT® is advanced into the material, providing infinitely variable sizes For use in sheet steel, non-ferrous metals, plastics, Formica and plywood The conical shape of the tool enables any size of hole to be drilled between the bottom and the top of the taper.When drilling metals always use a coolant. Conecut® applications:ElectricalHeatingVentilationPlumbingShop fitting installations etc.Auto body repairControl panelsSheet metalwork etc.MaintenanceThe Halls CC O CONECUT® High Speed Steel Sheet & Tube Drill Bit has the following specification: Size Range: 9.5 - 22.5mm.Chuck: 3/8in/10mm.
The Irwin HSS Pro TiN drill bits are primarily designed for drilling metal and harder, tougher alloys. Compared to traditional HSS twist drill bits, speed can be increased by 40 -60% and feed by 10 -20% without reducing the life time of the drill bit significantly. TiN is also a poor conductor of heat, so the heat generated during the drilling process is diverted into the chips and coolant and less into the drill bit. These drills have a 135° split point grinding tip which ensures perfect centring and reduced drilling pressure. The drill bit body is manufactured from high quality HSS steel coated with 2.5µ Titanium Nitride (TiN), the TiN coating has a hardness of app. 80 HRC and is very resistant to wear. TiN has a low coefficient of friction, this results in less power being consumed and less heat generated during the drilling.Irwin HSS Pro TiN Coated Drill Bit. Size 7.0 x 109mm.
The Irwin HSS Pro TiN drill bits are primarily designed for drilling metal and harder, tougher alloys. Compared to traditional HSS twist drill bits, speed can be increased by 40 -60% and feed by 10 -20% without reducing the life time of the drill bit significantly. TiN is also a poor conductor of heat, so the heat generated during the drilling process is diverted into the chips and coolant and less into the drill bit. These drills have a 135° split point grinding tip which ensures perfect centring and reduced drilling pressure. The drill bit body is manufactured from high quality HSS steel coated with 2.5µ Titanium Nitride (TiN), the TiN coating has a hardness of app. 80 HRC and is very resistant to wear. TiN has a low coefficient of friction, this results in less power being consumed and less heat generated during the drilling.The Irwin IRW10502585 HSS Pro TiN Coated Drill Bit comes in the following:Size: 4.5 x 80mm
The Irwin HSS Pro Drill Bit manufactured from high quality HSS steel. They have precision ground cutting edges for fast drilling and perfect finishing, a ground flute for maximum accuracy and fast chip removal and a universal 118º point shape for drilling a wide selection of materials. Manufactured to DIN 338 standards.Irwin HSS Pro Drill Bit. Size: 9.0 x 125mm.PVC Tube.
Dormer A100 Metric HSS jobber drills are suitable for use in the majority of general purpose engineering applications. They have good self-centring capability on a wide range of materials and are suitable for both hand and machine use. DIN338RNBS328ISO235Tip diameter: 8.60mm.Working length: 81mm.Overall length: 125mm.
